GUANGZHOU HUAHUI AUTO PARTS LTD

Name: LMG-10W Wireless Digital Manifold Gauge Set Data Logging Refrigerant HVAC Gauges with Hoses, Thermometer Clamps LMG-10
Brand: TUYoung
SKU: 18506622
Rating: 4.75 (10 reviews)

aftermarket vehicle a/c products

Home / All / Auto A/C Repair Tools /

LMG-10W Wireless Digital Manifold Gauge Set Data Logging Refrigerant HVAC Gauges with Hoses, Thermometer Clamps LMG-10

Categories	Auto A/C Repair Tools
Brand	TUYoung
Model	HY-TL321
Brand name	TUYOUNG
quality	top A
Item dimensions L x W x H	28.2 x 7 x 34.5 Centimetres
Measurement range:	-14.5~800psi/-1.0~56.2kg/cm2/-1.0~55.2bar/-0.1~5.
Accuracy:	±0.5%FS
Resolution	0.1psi/0.1kg/cm2/0.1bar/0.01MPa Unit: kPa，MPa，bar，
Temperature accuracy	±0.5℃/±0.9℉
Temperature resolution	0.1℃/0.2℉
Temperature unit	℃, ℉
Temperature measurement range	-40℃~150℃/-40℉~302℉
Unit	psi, kg/cm, bar, kPa, MPa
Power supply	3 xAA battery, 1.5V
Interface	114" SAE*3
FOB port	Huangpu Shenzhen
Terms of Payment	L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Download
Update Time	Apr 19,2025

Contact Now

Favorites

Detail Information

LMG-10W Wireless Digital Manifold Gauge Set Data Logging Refrigerant HVAC Gauges with Hoses, Thermometer Clamps LMG-10

TUYOUNG No.: HY-TL321

Spercification:

Item dimensions L x W x H： 28.2 x 7 x 34.5 Centimetres

Measurement range: -14.5~800psi/-1.0~56.2kg/cm2/-1.0~55.2bar/-0.1~5.5MPa

Accuracy: ±0.5%FS

Resolution: 0.1psi/0.1kg/cm2/0.1bar/0.01MPa

Unit: kPa，MPa，bar，psi，kg/cm2

Temperature measurement range: -40℃~150℃/-40℉~302℉

Temperature accuracy: ±0.5℃/±0.9℉

Temperature resolution: 0.1℃/0.2℉

Temperature unit: ℃, ℉

Interface:114" SAE*3

Package Includes:1 x digital manifold,2 xtemperature clamp, 3x refrigerant hose,1 x Case

88 RefrigerantTypes Available：R113 R114 R115 R116 R12 R123 R1233ZD R1234ZE R1234YF R124 R125 R13 R134aR23 R236FA R245FA R290 R32 R401AVB/C214 R141B R142B R143A R152A R170 R222402A RA02B RA03B RA04AR407D R407F R408A R409AR410AR410B R412AR413AR414AR414B R416AR417AR417C R420A R421A R421BR422AR422B R422C R422D R424AR426A R427AR428A R429A R434AR437A R438AR441A R443A R448AR449A R450A R452A R452B R453A R454A R454B R455AR458AR500 R502 R503 R507A R508AR508B R514A R600 R600a R601a R718 R744

OEM

LMG-10W

Intergraded app, Elitech Tools:

PROFESSIONAL TOOL：Monitoring the process of pressure holding and vacuum leakage test precisely with temperature compensationCOMPACT, PORTABLE & DURABLE: Ultra-low power consumption,longer battery life of 200 hours, replaceable battery.

MULT-FUNCTlONAL: Supports 88 types of refrigerants, auto calculation of overheating and supercooling, temperature compensation, auto-off 5pressure units: psi, kg/cm2, kPa, MPa, bar, and 2 temperature units.°F/C

UPGRADED ELITECH TOOLS APP(ios and Android)：: An intergraded app, that alows users to manage al Elitech tools as vacuum pump, digitalmanifold, vacuum gauge, pressure gauge, refrigerant charging scale on one app, more eficient and more intelligent.
